TS13CA SMD Aluminum Electrolytic Capacitor – Low Impedance for Power Applications

Component Overview

The TS13CA series is a surface mount aluminum electrolytic capacitor designed for applications requiring low impedance and stable performance at elevated temperature. The series supports long load life operation at +105 °C.

Electrical and Reliability Characteristics

• Maximum operating temperature: +105 °C
• Load life: 3000 to 5000 hours at rated temperature
• Low impedance structure
• Solvent-resistant construction (within 2 minutes exposure)

Assembly Compatibility

• Surface mount configuration
• Suitable for automated reflow assembly

Applications

• Switching power supply filtering
• DC output smoothing
• Industrial control electronics
• General low-impedance decoupling

Design Considerations

• Verify ripple current capability under operating temperature
• Apply voltage and temperature derating for lifetime optimization
• Confirm PCB land pattern for SMD aluminum electrolytic packages
• Evaluate impedance characteristics at switching frequency

For detailed electrical parameters and dimensional data, refer to the TS13CA datasheet.
