TS13C5 SMD Aluminum Electrolytic Capacitor – Extra Low Impedance Design

Component Overview

The TS13C5 series is a surface mount aluminum electrolytic capacitor designed for low impedance requirements in power supply and decoupling applications. The series operates across a wide temperature range and supports stable performance in high-density PCB layouts.

Electrical and Reliability Characteristics

• Operating temperature range: -55 °C to +105 °C
• Load life: 3000 hours at rated temperature
• Extra low impedance structure
• Impedance reduction of approximately 40% to 60% compared with TS13C4 series

Assembly Compatibility

• Surface mount configuration
• Suitable for automated reflow soldering processes

Applications

• Switching power supply output filtering
• DC bus decoupling
• Industrial control electronics
• High-frequency ripple current environments

Design Considerations

• Verify ripple current capability under operating temperature
• Apply voltage and temperature derating for lifetime optimization
• Confirm PCB land pattern for SMD aluminum electrolytic packages
• Evaluate impedance performance at switching frequency

For detailed electrical parameters and dimensional data, refer to the TS13C5 datasheet.
