TS13C4 SMD Aluminum Electrolytic Capacitor – Low Impedance Series

Component Overview

The TS13C4 series is a surface mount aluminum electrolytic capacitor designed for low impedance applications in power supply and decoupling circuits. The series supports operation across a wide temperature range and is compatible with lead-free reflow processes.

Electrical and Reliability Characteristics

• Operating temperature range: -55 °C to +105 °C
• Load life: 1000 to 2000 hours at rated temperature
• Low impedance structure
• Lead-free reflow compatible

Assembly Compatibility

• Surface mount configuration
• Suitable for automated reflow soldering

Applications

• Switching power supply filtering
• DC output smoothing
• Industrial control electronics
• General low-impedance decoupling

Design Considerations

• Verify ripple current capability at operating temperature
• Apply voltage and temperature derating for lifetime optimization
• Confirm PCB land pattern for SMD aluminum electrolytic packages
• Evaluate impedance performance at switching frequency

For detailed electrical parameters and dimensional data, refer to the TS13C4 datasheet.
