TS16 High Voltage Ceramic Capacitor and TS22 Y Safety Capacitor – Alternative Solutions

Product Background

With the discontinuation of certain high voltage ceramic capacitors and Y safety capacitors in the market, equivalent solutions are required for existing circuit designs.
TS16 and TS22 series are provided to support high voltage and safety-related capacitor applications.

TS16 – High Voltage Ceramic Capacitor

• Ceramic dielectric structure
• Designed for high voltage applications
• Suitable for circuits requiring elevated voltage endurance

High voltage ceramic capacitors are commonly used in power supply, industrial, and high voltage signal circuits where voltage stress conditions must be considered.

TS22 – Safety Standard Recognized Capacitor (Y Type)

• Y safety capacitor category
• Designed for safety-related applications
• Applicable in circuits requiring insulation between line and ground

Y capacitors are typically used in EMI suppression circuits and must comply with safety standards for across-the-line or line-to-ground applications.

Applications

• Power supply input stages
• EMI suppression circuits
• Industrial electronic equipment
• High voltage control systems

Design Considerations

• Verify voltage rating relative to operating conditions.
• Confirm safety classification requirements for Y capacitor applications.
• Ensure creepage and clearance distances meet design standards.
• Review datasheet specifications prior to qualification.

Reference Documents

TS16 Datasheet:

http://www.suntan.com.hk/pdf/Ceramic-Capacitors/TS16.pdf

TS22 Datasheet:

http://www.suntan.com.hk/pdf/Safety-Capacitors/TS22.pdf
