TS05S Metallized Polyester Film Capacitor – Replacement for Stacked Film Capacitors

Product Background

Following the discontinuation of certain stacked metallized film capacitors in the market, TS05S provides an alternative solution within the metallized polyester film capacitor category.

Product Overview

TS05S is a metallized polyester film capacitor featuring a plastic case and epoxy resin sealing. The stacked construction enables compact size while maintaining electrical performance suitable for pulse-related applications.

Technical Characteristics

• Metallized polyester film dielectric
• Stacked construction
• Plastic case with epoxy resin sealing
• High dV/dt capability
• Compact mechanical size

Applications

• Pulse circuits
• Signal coupling and filtering
• Industrial control electronics
• General-purpose electronic equipment

Design Considerations

When replacing a stacked film capacitor with TS05S, engineers should verify capacitance value, rated voltage, dV/dt requirements, and mechanical dimensions. PCB layout compatibility and thermal conditions should also be reviewed to ensure proper integration into the existing circuit design.

Datasheet

For detailed electrical parameters and dimensional specifications, please refer to:

http://www.suntan.com.hk/pdf/Plastic-Film-Capacitors/TS05S.pdf
