TSC3 Series – SMD Ceramic Trimmer Capacitor Technical Overview

Product Introduction

The TSC3 series is a surface-mount (SMD) ceramic trimmer capacitor designed for fine capacitance adjustment in compact electronic circuits.
The series includes 3mm SMD ceramic trimmer capacitors and special 3mm SMD variants.

Operating Conditions

• Operating temperature range: -25°C to +85°C
• Designed for reflow soldering processes
• Low capacitance drift after adjustment

Mechanical and Structural Characteristics

• Ultra-thin dustproof structure
• Easy adjustment mechanism
• Housing material: high-temperature liquid crystal polymer (LCP)
• Low dielectric loss
• High mechanical strength

Application Areas

• RF tuning circuits
• Frequency calibration modules
• Communication equipment
• Compact consumer electronics
• Precision signal adjustment circuits

Engineering Considerations

When selecting a ceramic trimmer capacitor, engineers should verify:

• Capacitance adjustment range
• Capacitance drift stability
• Reflow temperature compatibility
• Mechanical footprint and PCB layout constraints
