SMD Ceramic Trimmer Capacitors – TSC3S Series (RoHS Compliant)

Product Overview

TSC3S series SMD ceramic trimmer capacitors are designed for fine capacitance adjustment in compact electronic circuits. The surface-mount structure supports automated assembly and space-constrained PCB layouts.

Available Stock Models

• TSC3S506T1 – 2pF to 6pF, Blue, RoHS compliant
• TSC3S510T1 – 3pF to 10pF, Ivory, RoHS compliant
• TSC3S530T1 – 8pF to 30pF, Green, RoHS compliant

Technical Characteristics

• Surface-mount ceramic trimmer construction
• Adjustable capacitance range for tuning applications
• RoHS compliant
• Color-coded capacitance range identification

Applications

• RF tuning circuits
• Oscillator frequency adjustment
• Impedance matching networks
• Compact wireless modules

Design Considerations

When selecting an SMD trimmer capacitor, engineers should confirm the required capacitance adjustment range and verify mechanical accessibility for post-assembly tuning. Proper PCB land pattern and grounding layout are recommended to maintain frequency stability and minimize parasitic effects.
