SMD Crystal Oscillator for Reflow-Compatible Automatic Assembly

Product Overview

The SMD Crystal Oscillator is designed for automatic mounting, reflow soldering, and washing processes. The surface-mount structure supports high-volume SMT production and stable frequency generation in digital and RF systems.

Key Technical Features

• Surface-mount package for automated assembly
• Compatible with reflow soldering processes
• HCMOS compatible logic levels
• Low power standby mode
• Pb-free and RoHS compliant
• Available sizes: 3.2 × 2.5 mm, 5.0 × 3.2 mm, 7.0 × 5.0 mm

Applications

• Communications equipment: ADSL, routers, intercom systems, IP telephones, WiFi modules, GPS modules, RF modules
• Security systems: monitoring cameras, entrance guard systems, anti-theft devices
• Consumer electronics: car stereos, DVB systems, smart metering devices, remote control toys, MP3/MP4 players, wireless microphones, digital photo frames, card readers

Design Considerations

When selecting an SMD crystal oscillator, engineers should verify frequency specification, logic output compatibility, and power consumption requirements according to system design. PCB layout should follow recommended land pattern and grounding practices to ensure stable oscillation and signal integrity, particularly in RF and high-speed digital applications.

Further Information

For detailed specifications and available models, please refer to:

http://www.suntan.com.hk/Quartz-Crystal/
