TS16 High Voltage Ceramic Capacitor for 1kV to 15kV Applications

Component Overview

The TS16 series ceramic capacitor is designed for high-voltage applications, supporting rated voltages from 1kV to 15kV.
It is suitable for circuits requiring stable insulation performance and reliable operation under elevated voltage stress.

Electrical Characteristics

• Rated voltage range: 1kV to 15kV
• Ceramic dielectric construction
• Designed for high-voltage circuit environments

Performance Features

• Suitable for high-voltage insulation requirements
• Stable electrical performance under elevated voltage conditions
• Applicable to specialized high-voltage electronic systems

Applications

• High-voltage power supplies
• Industrial control equipment
• Testing and measurement instruments
• High-voltage signal coupling circuits

Design Considerations

• Select rated voltage with sufficient margin over operating voltage
• Ensure PCB creepage and clearance distances meet high-voltage standards
• Consider insulation and environmental conditions
• Verify capacitance value according to circuit requirements

Datasheet

For detailed specifications, refer to the official datasheet:
TS16 Series Datasheet
